Single disc brake, diameter 10.9" (276 mm), double-piston floating caliper
ABS System
BMW Motorrad Integral ABS Pro (part-integral, slant-layer-optimized)
Chassis and Suspension
Frame
Two-section frame, front- and bolted on rear frame, load-bearing engine
Front Suspension
BMW Motorrad Telelever; stanchion diameter 1.5" (37 mm), central spring strut
Rear Suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Tyres
Wheels / Rim
Cast aluminum wheels
Front Tyre
3.00 x 19“
120/70 R 19
Rear Tyre
4.50 x 17“
170/60 R 17
Dimensions
Length
2207mm
Width
952mm
Height
1430mm
Seat Height
850 mm
Wheelbase
1514 mm
Kerb Weight
249 kg
Fuel Tank Capacity
24 litres
Reserve Tank Capacity
5 litres
Additional Details
Emission control: Regulated three-way catalytic converter
Fuel type: Premium Unleaded
Alternator: Three-phase generator with 510 Watt nominal power
Caster: 4.0" (100.6 mm)
Steering head angle: 64.3°
Inner leg curve: 1,870 mm / 1,910 mm (OE lowered suspension 1.750 mm / 1.790 mm)
