Rated Power: 6 kW (8 HP) at 900 RPM
Peak Power: 8 kW (12 HP) at 960 RPM
Maximum Torque
195 Nm
Load Carrying Capacity
260 kg
Top Speed
90kmph
Riding Modes
Eco, Normal & Sport
Motor Details
Hub Permanent magnet motor (PSM)
Range
Eco Mode: 105 km
Normal Mode: 85 km
Speed Mode: 65 km
Charging Time
80 % in 3 hours
Display
Battery SoC, voltage, speedometer, odometer, trip meter, ride mode, time and telltales.
Electricals
Battery
Cells: Premium 18650 Li-Ion cells
Configuration: 2 battery packs in serial
Voltage: 104 V
Capacity: 35 Ah / 3.6 kWh
Peak Current: ~90 A
Battery Voltage Range: 90 – 117 V
Dimensions: 310 mm x 220 mm x 100 mm
Weight: 2 x 11.5 kg
Connector: QS8-S Anti Spark
Life Cycle: Rated for 800 Charge C
Controller
Controller Type: Electronic Sine Wave (BLDC)
Head Lamp
LED
Brakes
Front Brake
CBS Hydraulic Disc Brake 265 mm Disc with 4 mm thickness
Rear Brake
CBS Hydraulic Disc Brake 220 mm Disc with 3 mm thickness
Brake Lever
Brake Fluid Type: DOT 4
Regenerative Braking: Activates when you brake
Chassis and Suspension
Front Suspension
Hydraulic forks featuring 31mm tubes for extra rigidity and strength.
Travel: 200mm
Rear Suspension
Adjustable 335mm dual shocks
Tyres
Wheels / Rim
Hub: Aluminum hubs with 12 mm axle
Front Rim: 1.85 x 18” 36 spoked aluminum rims
Rear Rim: 2.15 x 18” 36 spoked aluminum rims
Front Tyre
90/90 – 18 Heidenau Dual Sport K60
Rear Tyre
110/80 – 18 Heidenau Dual Sport K60
Dimensions
Length
1900mm
Width
700mm
Height
1250mm
Seat Height
780 mm
Wheelbase
1300 mm
Weight
109kg
Kerb Weight
86 kg
Accessories
- Rear Rack
- Front Grill
- Battery Box protection or Fork Stabilisators
Additional Details
Class: L3e (EU) & Motor driven cycle (USA)
License: A1 (EU) / M1 (USA)
Fork Angle: 24.5 °
Environmental Protection: IP54
Throttle Type: Full Twist DOMINO Hall (IP66)
