BEB full carbon 3K, 640 mm width, 31.8 mm diameter, Spacer full carbon
Fork
Air suspension fork 32 mm stanchions, 100 mm travel with LockOut and adjustable compression and rebound damping
Seat
Seat clamp : BEB 31.8 mm
Seatpost
BEB CNC Superlight 27.2 mm, 300 mm long
Grip
SLR, breathable
Saddle
BEB Race Superlight with 7 mm Titan-Rails
Headset
BEB semi-integrated 1 1/8 "
Spoke
Sapim Race butted 2.0 / 1.8 / 2.0 mm
Motor Details
Brushless DC hub motor
Display
OLED-Display with 5 support levels
Electricals
Battery
250 Wh battery, integrated BMS with all protection functions
Brakes
Front Brake
180 mm Rotoren Ashima AiRotor , Magura MT Sport
Rear Brake
160 mm Rotoren Ashima AiRotor , Magura MT Sport
Chassis and Suspension
Frame
26 inch frame AL6061,BEB "Smoother 26" by Spinner USA
Tyres
Wheels / Rim
Rims -Alexrims MD19
Hollow chamber
28 holes Front wheel hub PLP Superlight
Quick release front BEB Superlight
Front Tyre
Schwalbe ROCKET RON ADDIX 26 x 2.10
Rear Tyre
Schwalbe ROCKET RON ADDIX 26 x 2.10
Tube
Schwalbe AV14A
Dimensions
Weight
13.1kg
Additional Details
KSA18-Mounting for stand
BEB Sine Wave Controller, freely configurable via PC software via USB
12-poliger PAS Pedal sensor, speed sensor and hall sensors
Maximum rider weight : 90 kg
