BEB Superlight 40 mm with 31.8 mm clamping, Spacer full carbon
Handlebar
BEB full carbon 3K, 640 mm width, 31.8 mm diameter
Fork
BEB Smoother air suspension fork by Spinner, 32 mm stanchions, 100mm travel with LockOut and adjustable pressure and rebound damping
Seat
Seat clamp BEB 31.8 mm
Seatpost
BEB CNC Superlight 27.2 mm, 350 mm long
Crankset
Crankset with 165 mm crank length, forged chainring 32 teeth narrow-wide
Pedals
CNC pedals with titanium axles and sealed bearings
Chain
KMC X10-93, 112 links
Shifters
Shift cables Shimano
Saddle
BEB Race Superlight with 7 mm titanium rails
Headset
BEB semi-integriert 1 1/8"
Derailleur : Rear
Sunrace RDMX60 (compatible up to 11-50Z)
Hub : Front
BEB Superlight ,Quick release front BEB Superlight
Spoke
Sapim Race butted 2.0 / 1.8 / 2.0 mm
Cassette
Sunrace cassette CSMX3 with aluminum spider, 11 - 42 teeth
Motor Details
Brushless DC hub motor
Display
TFT color display with 5 support levels
Electricals
Battery
250 Wh or 375 Wh battery, integrated BMS with all protection functions
Brakes
Front Brake
Magura MT Sport ,180 mm Rotoren Ashima AiRotor
Rear Brake
Magura MT Sport ,160 mm Rotoren Ashima AiRotor
Chassis and Suspension
Frame
27.5 inch frame AL6061 hydroforming, 460mm seat tube length
Tyres
Wheels / Rim
Rims Alexrims MD19, hollow chamber, 28 holes
Front Tyre
Schwalbe ROCKET RON Evolution LiteSkin 27.5 x 2.25 tires ,Kenda UltraLite
Rear Tyre
Schwalbe ROCKET RON Evolution LiteSkin 27.5 x 2.25 tires,Kenda UltraLite
Dimensions
Weight
13.6kg
Additional Details
Bottom Bracket : Neco bottom bracket with carbon housing and hollow-drilled CrMo axle
Controller : BEB Sine Wave Controller, freely configurable via PC software via USB
Sensors : 12-pin PAS pedal sensor, speed sensor and hall sensors
Maximum rider weight : 90 kg
