Up to 28 MPH on Pedal Assist and 20 MPH on Throttle
Stem
Threadless, 31.8mm, 7 Degree Rise
Handlebar
Aluminum 31.8mm, 680mm
Seat
31.8 mm Quick Release
Seatpost
Aluminum Alloy, 27.2mm, 2-Bolt Clamp
Grip
Ergonomic Comfort
Crankset
170mm w/ 46 T
Pedals
9/16" Alloy Platform
Pedal Assist System - PAS
5 Levels
Chain
122 Link, 8 Speed
Shifters
8 Speed
Saddle
Aventon by Velok
Headset
Sealed Bearing Headset
Derailleur : Rear
8 Speed
Hub : Front
36H Disc Thru-axle Front, Nutted Rear
Spoke
Black Stainless 13G Front / 12G Rear
Cassette
12-32T, 8 Speed Cassette
Bottom Bracket
Square Taper, Sealed, Torque Sensor
Stand
Included, Rear Mount
Motor Details
750W (Peak) 500W (Sustained) Brushless Rear Hub Motor
Range
Up To 60 Miles*
Display
LCD Smart Easy Read Display with Backlight, Colorful screen with app
Electricals
Battery
Removable Internal Lithium-ion 48V, 14Ah (672Wh)
Charger
48V 3 Amp Fast Charger, 4-5 Hour Charging
Brakes
Front Brake
Hydraulic Disc Brakes, 180mm Rotors
Chassis and Suspension
Frame
6061 Double-Butted Aluminum Alloy with Internal Battery
Front Suspension
Coil Spring Suspension, Thru-axle, 65mm travel with lockout
Tyres
Wheels / Rim
Double Wall Aluminum 36h Front & Rear
Front Tyre
27.5” x 2.1” Hybrid Tires, Reflective Sidewalls
Tube
Butyl Rubber, Schrader Valve
Dimensions
Wheelbase
1095 mm
Weight
24kg
Additional Details
Throttle: Throttle on demand - Throttle from a complete stop
SENSORS: Torque Sensor
Top Tube Length: 572mm
Reach: 373mm
Head Tube Length: 120mm
Standover Height: 477mm
Min Saddle Height: 810mm
Max Saddle Height: 975mm
